Summary

EnginePartsCenters is your number one source for engine rebuilding and engine restoration needs!

Speed Pro Forged COATED Pistons+Moly Rings for Chevrolet 396

P/N L2242NF-KIT

About Speed Pro street series power forged pistons:

Higher compression, longer life.
These Speed-Pro forged pistons are made from extruded VMS-75 aluminum alloy that's forged under 3,000 tons of pressure to "near-net" shape. After that, they're machined to their final configuration. These pistons offer excellent strength and durability and are capable of taking the punishment that's dished out on the street and in competition. They're available for a wide variety of applications, including OE replacements and all-out racing engines.

Federal Mogul/Speed Pro Piston Part
Number

Application

Power Range

Special requirements

Compression information

Ring groove size

Pin diameter

Rod length

Stroke

Deck clearance

Skirt clearance

L2242NF+60 plus a moly ring set (Perfect Circle/MAHLE) P/N L2242NF-KIT -

These pistons are not available in standard size

Chevrolet 396 - 4.155" bore (at +.060")

Domed head .352" high. DurOshield skirt coated piston. Special Hi-Perf.

1968-69 396-375HP; closed chamber heads..

idle to 7000+rpm

Good for street or race/nitrous to 150 shot

1.765" compression distance

Approx. Compression (w/.030" bore):

w/109.4cc chambers 10.58:1

5/64" 5/64" 3/16" ring grooves

.9897" pin diam. - pins included

for stock length 6.135" rods

PRESS-fit only

Stock 3.766" stroke

.025" deck clr

.0015" skirt clr
